Basic Info.

Model NO.	Dse7410
Mathematical Model	Linear
Signal	Discrete
Function	Automatic Control, Protection, Monitoring, Measurement
Certification	RoHS, CCC, ISO: 9001, CE
Condition	New
Customized	Customized
Material	Plastic
Controller	Dse7410
Brand	Deepsea
Start	Auto
Output Type	DC Type
Functionality	Control Module
Transport Package	Foam Plastic Packaging
Specification	245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")
Trademark	Deep Sea
Origin	China
HS Code	8503009090
Production Capacity	10000/Month

Product Description

VIGKOO provides diesel generator power spare parts and engineering accessories worldwide, including Cummins, Cat, Perkins, Deutz, Volvo, Doosan and Chinese engine parts, original brand generator Stamford, Leroy-somer, Mecc-alte and other related components, As well as engine spare parts, controller modules, circuit breakers, light towers, external fuel tanks, cables, door locks, antivibration pads, etc., customized ATS systems, parallel control systems, etc. VIGKOO will bring great enthusiasm and unremitting efforts and committed to becoming a top enterprise in international power accessories.

VIGKOO is specialized in diesel engines, generator sets, and spare parts.

We supply all kinds of accessories for diesel engine,like cylinder head,cylinder head cover,cylinder block,alternator,turbocharger,piston,piston ring,piston pin,liner,crankshaft,cam shaft,main bearing,connecting rod,connecting rod bearing,water pump,oil pump,injector,fuel injection pump,starter motor,fan,belt,gasket,oil pan,flywheel,intake valve,exhaust valve and so on.

1. Why Choose us?
Vigkoo has a wide range of cooperative supplier groups. Whether you need to find which power equipment products, Vigkoo can help you quickly enter the Chinese supply system and obtain the latest market products and competitive prices.

2. Delivery Time?
Spare parts for about 3-5 days. Diesel generator set about 30-50 days.

3. Manufacturer or Trade Company?
We have our own factory for OEM manufacture producing, also trade with all electrical parts.

4. Global Warranty?
Yes, usually global warranty 1 year / 1000 hours. Provide extended warranty service for 2 years / 2000 hours, 3 years, 5 years... ...

5. Payment terms?
L/C, T/T, Western Union, PayPal

6. Customized service?
Provide customized services according to the customer requirements

DSEGenset® is an intelligent range of single-set and multi-set generator control solutions, mains (utility) protection relays, lighting tower control solutions, digital automatic voltage regulators (AVR's), remote communications devices and expansion modules. Each range has been designed and manufactured by our industry leading experts to deliver a range of features and benefits that set new standards across the industry.

The DSE7410 MKII is an intelligent, powerful auto start control module with high-level features and functionality. The control module is the first module in the DSE range to include in-built SNMP and features an embedded web server. The module is suitable for a wide range of single-set gas and diesel applications. The control module features an enhanced dual core main processor and extended memory capacity. This allows the module to deliver a faster more powerful performance to return quicker operating responses on complex applications and provides enhanced memory storage for high level data logging functionality.

DSE7410 MKII

Auto Start Control Module

OVERALL SIZE

245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")

PANEL CUTOUT SIZE

220 mm x 160 mm (8.7" x 6.3")

MAXIMUM PANEL THICKNESS

8.0 mm (0.3")

WEIGHT

0.88kg

PRODUCT VARIANTS

7410-03 - 7410 MKII Auto Start Control Module

SPECIFICATION

DC SUPPLY

CONTINUOUS VOLTAGE RATING
8 V to 35 V Continuous
5 V for up to 1 Minute

CRANKING DROPOUTS
Able to survive 0 V for 100 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries

MAXIMUM OPERATING CURRENT
510 mA at 12 V, 240 mA at 24 V

MAXIMUM STANDBY CURRENT
330 mA at 12 V, 160 mA at 24 V

CHARGE FAIL/EXCITATION RANGE
0 V to 35 V

INPUTS

DIGITAL INPUTS A-H
Negative Switching

ANALOGUE INPUTS A,B, E & F
Configurable as
Negative Switching Digital Input
0 V to 10 V Sensor
4mA to 20mA Sensor
Resistive Sensor

ANALOGUE INPUTS C & D
Negative Switching Digital Input
Resistive Sensor

OUTPUTS

OUTPUT A (FUEL)
15 A DC at supply voltage

OUTPUT B (START)
15 A DC at supply voltage

OUTPUTS C & D
8 A AC at 250 V AC (Volt free)

AUXILIARY OUTPUTS E,F,G,H,I & J
2 A DC at supply voltage

GENERATOR

VOLTAGE RANGE
15 V to 415 V AC (Ph-N)
26 V to 719 V AC (Ph to Ph)

FREQUENCY RANGE
3.5 Hz to 75 Hz

MAGNETIC PICK UP

VOLTAGE RANGE
+/- 0.5 V to 70 V

FREQUENCY RANGE
10,000 Hz (max)
